| Item |
P/N |
Description |
Qty. |
| 1 |
A H 1 6 0 2 0 1 - 0 1 0 4 0 0 |
D i s c h a r g e H y d r a u l i c c y l i n d e r a s s e m b l y |
3 |
| 2 |
A H 1 6 0 2 0 1 - 0 1 0 5 0 0 B 1 |
S u c t i o n p i p e l i n e |
1 |
| 3 |
A H 1 6 0 2 0 1 - 0 1 0 7 B 2 |
A n t i - a b r a s i v e φ 1 9 0 |
3 |
| 4 |
A H 1 6 0 2 0 1 - 0 1 0 8 |
D i s c h a r g e p i p e l i n e |
1 |
| 5 |
A H 1 6 0 2 0 1 - 0 1 1 0 B 1 |
S u c t i o n H y d r a u l i c c y l i n d e r |
3 |
| 6 |
A H 1 6 0 2 0 1 - 0 1 1 1 0 0 |
P i s t o n |
3 |
| 7 |
A H 1 6 0 2 0 1 - 0 1 1 3 |
H y d r a u l i c c y l i n d e r s e a l i n g r i n g |
3 |
| 8 |
A H 1 6 0 2 0 1 - 0 1 1 4 |
D i s c h a r g e p i p e s e a l i n g r i n g |
3 |
| 9 |
A H 1 6 0 2 0 1 - 0 1 1 5 |
A n t i - a b r a s i v e s e a l i n g r i n g |
3 |
| 10 |
A H 1 6 0 2 0 1 - 0 1 1 6 B 4 |
C y l i n d e r s l e e v e s e a l i n g r i n g ( φ 1 7 0 ) |
3 |
| 11 |
A H 1 6 0 2 0 1 - 0 1 1 6 B 5 |
C y l i n d e r s l e e v e s e a l i n g r i n g ( φ 1 8 5 ) |
3 |
| 12 |
A H 1 6 0 2 0 1 - 0 1 1 6 B 6 |
C y l i n d e r s l e e v e s e a l i n g r i n g ( φ 2 2 0 ) |
3 |
| 13 |
A H 1 6 0 2 0 1 - 0 1 1 8 0 0 |
C y l i n d e r s l e e v e |
3 |
| 14 |
A H 1 3 0 1 0 1 - 0 5 1 8 |
C y l i n d e r s l e e v e l o c k r i n g |
3 |
| 15 |
A H 1 6 0 2 0 1 - 0 1 2 2 B 1 |
Va l v e d e c k s e a l i n g r i n g |
6 |
| 16 |
5 3 0 3 0 1 0 1 2 0 0 0 0 7 0 0 1 5 |
O r i n g φ 2 0 0 * 7 . 0 0 F P M |
3 |
| 17 |
A H 1 0 0 1 0 1 - 0 5 2 9 |
Va l v e s p r i n g |
6 |
| 18 |
A H 1 6 0 2 0 1 - 0 1 1 9 0 0 B 1 |
Va l v e a s s e m b l y A P I 7 |
6 |
| 19 |
5 3 0 3 0 1 0 1 1 8 5 0 0 7 0 0 1 5 |
O r i n g φ 1 8 5 * 7 . 0 0 F P M |
3 |
| 20 |
A H 1 3 0 1 0 1 - 0 5 1 9 0 0 |
C l a m p a s s e m b l y |
3 |
| 21 |
A H 1 3 0 1 0 1 - 0 5 2 0 |
C y l i n d e r s l e e v e e n d c o v e r |
3 |
| 22 |
A H 1 3 0 1 0 1 - 0 5 1 5 B 1 |
C y l i n d e r s l e e v e p r e s s u r e c o v e r |
3 |
| 23 |
A H 1 3 0 1 0 1 - 0 5 1 4 |
C y l i n d e r s l e e v e f l a n g e |
3 |
| 24 |
T 5 0 7 - 3 0 5 . 0 0 |
L o c k N u t M 3 9 * 3 |
3 |
| 25 |
A H 1 3 0 1 0 1 - 0 5 2 3 0 0 |
G a s k e t s e t |
4 |
| 26 |
5 2 0 2 0 3 0 8 0 2 0 0 4 0 0 0 0 2 |
I n n e r j o i n t N P T 1 1 / 2 " |
1 |
| 27 |
A H 1 0 0 1 0 1 - 0 5 2 6 |
S u c t i o n f l a n g e ( I I ) |
1 |
| 28 |
5 3 0 3 0 1 0 1 3 4 5 0 0 7 0 0 1 5 |
O r i n g φ 3 4 5 * 7 . 0 0 F P M |
3 |
| 29 |
A H 1 0 0 1 0 1 - 0 5 2 5 |
S u c t i o n f l a n g e ( I ) |
1 |
| 30 |
4 2 0 2 0 1 0 1 1 1 2 7 0 9 0 0 6 0 |
B o l t M 2 7 * 9 0 - 8 . 8 - Z n . D |
36 |
| 31 |
A H 0 0 0 0 0 5 - 0 8 0 0 |
S u c t i o n a i r d o m e |
1 |
| 32 |
4 2 0 4 0 2 0 1 6 2 7 0 4 0 0 0 0 0 |
N u t M 2 7 - 8 - Z n . D |
36 |
| 33 |
A H 1 0 0 1 0 1 - 0 5 2 7 |
W a s h e r 3 9 |
30 |
| 34 |
420201011122050060 |
Bolt M22*50-8.8-Zn.D |
18 |
| 35 |
AH160201-012000B3 |
Spraying pipe assembly |
1 |
| 36 |
AH100101-0515B1 |
Piston sealing ring |
3 |
| 37 |
AH160201-0121 |
90°bend NPT3/8 |
3 |
| 38 |
AH000002-0900B1 |
HP valve assembly |
6 |
| 39 |
170506010100243000 |
Loctite glue 243 |
1 |
| 40 |
441305011104164038 |
Ball valve Q11SF-16P NPT1 1/2" |
1 |
| 41 |
AH160201-0107B1 |
Wear-resisting diskφ180 |
3 |
| 42 |
AH160201-0116B7 |
Cylinder sleeve lock ring(φ200) |
3 |
| 43 |
AH130101-0516 |
Piston rod |
3 |
| 44 |
AH160201-012300 |
Valve cover assembly |
6 |
